The VKF 90 is a thermoformer designed for very high productivity lines, where the pieces produced per minute count and the business continuity.
THElarge forming area allows you to create a large number of packages for each cycle, while maintaining precision and uniformity even at high speeds.
Designed for complex industrial environments, the VKF 90 is ideal for fully automated lines and forintegration of printing systems, labeling and end of line
Choosing the VKF90 means focusing on a thermoformer designed to manage large production volumes continuously, ensuring process stability, integration with automatic systems and constant packaging quality even at the highest rates.
Precise controls and advanced cutting systems optimize material use, reducing waste and production costs.
The VKF90 easily integrates with robotic loading systems, weighers and end-of-line solutions, becoming the heart of continuous and automated production.
Frame and mechanical components are designed to work 24 hours a day, ensuring operational stability and reducing maintenance interventions even on extended shifts.
Intelligent sensors and PLCs allow the automation of temperature, pressure and cycle time parameters, limiting manual errors and ensuring production uniformity.
Designed to meet the specific needs of your market, this technology guarantees excellent performance and maximum protection for a wide range of products.
Measurable performance and consistent reliability. View the technical specifications or download the full data sheet to discover the technology that powers your production
Length|From 5985 to 8985 with extension of 600 Width|1190 ÷ 1390 Height|1970 (± 50) Load area|According to customer usage Load area height|Fully customizable Total weight (vacuum pump excluded) |from 2500 kg Control panel height|1500 (± 50) Lower standard film width|Fully customizable Max.|1200 step Forming depth|80/120/150/190 - Special 220 Coil inner diameter|3” (70 ÷76 mm) Lower reel diameter|500 Top reel diameter|400 Material|Aisi 304 stainless steel Control/Command System|"Touch 12" Control/Command Interface|HMI Simatic Siemens - Windows CE Power system (Drive) |Brushless motor System installed (pump excluded) |20-40 kW - 440 V - 50/60 Hz - 3P + N + GND IP/NEMA|IP 66/NEMA 4 protection level Pneumatic supply|2500 Nl/min Electrical Components|Siemens, Toshiba, ABB, Sick, Phoenix Contact Mechanical Components|Rossi Gear Motors, Minimotor, Siemens, Iwis, SKF, Igus Pneumatic components | Festo, Parker Vacuum system components|OMAL, Valvaut, Maros Engineering, Trelleborg Production capacity|up to 22 cycles/min (depending on the product) Applications|Welding, Skin, MAP, Vacuum Bottom film for rigid packaging|PET - PVC - PS - PP Bottom film for flexible packaging|PA/PE Superior film for flexible packaging|PA/PE - PP - Paper - Alu - Tyvec - Skin
Choose the ideal storage method to enhance your production standards and ensure long-lasting freshness.
Sealing
Map
Skin
Vacuum
From the management of flexible and rigid films To the attention of the new sustainable materials: VKF thermoformers are designed to offer maximum technical versatility.
Thanks to a precise control of temperatures and times, we work on a wide range of thicknesses, aiming to guarantee hermetic welds and integrity of the pack.
Our technology is designed to accommodate the evolution of recyclable materials, subject to technical assessment to always ensure the required quality standard.
Oltre la tecnologia, la forma perfetta: scoprite come le nostre soluzioni trasformano ogni prodotto in un packaging sicuro, efficiente e dal design impeccabile.
.avif)
.avif)
.avif)
.avif)
MAP solutions on paper support for sustainable packaging that enhances the freshness of the product.
Scopri il caso studio
From compact solutions to high-throughput systems: explore the models in the Veripack range and find the perfect technology to scale your business.
Are you looking for a reliable partner for your packaging?
Start here: tell us about your project and together we’ll develop the ideal solution for your products
